Item: EX10060981 | Model: MSW-RPLAT25
Perfect for commercial jobsites, for rental or for do-it-yourselfers and homebuilders: The reversible plate compactor from MSW effortlessly compacts loose ground, beautifully asphalts small areas and flawlessly lays pavers. With 6.5 hp and a plate size of 62 x 40 cm, the forward and reversible plate compactor is ideal for small areas in gardening and landscaping work. The reversible plate compactor's direction can be controlled via a hand gear, whereas forward plate compactors can only move forward.
The vibrating plate with its 6.5 hp four-stroke engine can produce up to 25 kN of force at 4,300 vibrations/minute. This not only reliably compacts the ground to a depth of 30 cm, but also works exceptionally quickly. At a rate of up to 15 m/minute, the entire operation is extremely efficient. The ground compactor measures 62 x 40 cm, making it especially manoeuvrable and able to navigate even difficult-to-access or particularly narrow areas. With its rounded edges, this professional plate compactor can compact the ground without leaving marks. The vibratory plate compactor is very easy to steer and operate, making it ideal for use by ambitious do-it-youselfers. This model has two smooth-rolling wheels for easy transportation. The wacker plate's handle can be folded and locked for space-saving and safe storage. The plate compactor comes with a protective rubber mat for compacting paving stones.
Model
MSW-RPLAT25
Centrifugal force
25 kN
Power
6.5 hp
Direction
Forwards / backwards
Shipping dimensions (LxWxH)
71.00 x 43.00 x 110.00 cm
Weight
127 kg
Delivery package
Reversible plate compactor MSW-RPLAT25 2 wheels Instruction manual
Condition
New
Compaction depth
30 cm
Vibration frequency
4,300 VPM
Dimensions (LxWxH)
73.00 x 40.00 x 110.00 cm
Shipping weight
140.00 kg
Shipping dimensions (LxWxH)
71 x 43 x 110 cm
Plate size
62 x 40 cm
Speed
15 m/min
Motor
1 cylinder, 4-stroke, petrol, air-cooled, OHV
Weight
127.00 kg
Dimensions (LxWxH)
73 x 40 x 110 cm
Shipping weight
140 kg
Technical - manual
